10.1 inch Rack Mount Industrial LCD Monitor

  • 10.1 inch Rack Mount Industrial LCD Monitor
  • The 10.1 inch rack mount industrial monitor AMG-10IPDB01T1 developed by Amongo Display is a suitable model to be installed in places with demanding environment with the below features:
    • Original lcd panels with perfect image quality and long life span, industrial-grade components supporting long time running;
    • 10-points capacitive touch technology with surface Mohs 7 hardness;
    • Robust mechanical design to ensure stable quality and function in harsh working conditions.
    • Easy-to-install with rack mounting enclosures and vesa holes
    • Customization service available
    Application: Industrial automation,
    Contact Us

Model Name

AMG-10IPDB01T1

Screen Size

10.1"

Active Display Area(mm)

216.96(H)x135.6(V)

Pixel Pitch(mm)

0.1695(H)x0.1695(V)

Display Resolution (pixel)

Normally Black

Contrast Ratio

1280x800

Display Mode

16.7M

Touch screen(optional)

800:1

Brightness (cd/㎡)

350nits

Backlight

LED

Viewing Angles (CR=10)

170(H);170(V)

Response Time(Typ.Tr+Tf)

25ms

Touch Screen

PCAP Touch(10 points)

Light Sensor

Optional

Tempered glass

Optional

Dimension(VxHxT)

288x209x35

Signal Connector

HDMI/DP

Power Input

DC 12V

Touch Controller

USB

Operating Systems Support

Windows 7/8/10 / Linux(optional)

Operating Temperature

-20~70℃(non-condensation)

Storage Temperature

-30~80℃(non-condensation)

Relative Humidity

5(%RH)~90(%RH)
