15.6 Inch Panel Mount LCD Monitor

  • 15.6 Inch Panel Mount LCD Monitor
  • The industrial grade panel mount LCD monitor AMG-15IPPC01T4 offered by Amongo is ideal for both industrial and commercial industries environments with the following features:
    • Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
    • Wide range of touchscreen technologies including PCAP, Resistive, IR etc
    • High-end mechanical design to meet tough environmental conditions and requirements;
    • IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
    • Customization service available;
    Contact Us

Specifications

Model Name

AMG-15IPPC01T4

Screen Size

15.6"

Active Display Area (mm)

344.16 (H) x 193.59 (V)

Pixel Pitch (mm)

0.17925 (H) x0.17925 (V)

Display Mode

Normally white

Display Resolution (pixel)

1920x1080

Contrast Ratio

400:1

Display Color

262K colors

Brightness (CD/㎡)

270

Backlight

LED

Viewing Angles (CR =10)

140 (H); 120(V)

Response Time(Typ.Tr+Tf)

8ms

Signal Connector

VGA/DVI/DC 2.0

Power Consumption

DC 12V

Dimension(VxHxT)

422.4x271.7x56.7

Operating Temperature

0~50℃

Storage Temperature

-20~60℃

Relative Humidity

5(%RH)~90(%RH)
