10.1 inch PCAP Touch Screen LCD Monitor

  • 10.1 inch PCAP Touch Screen LCD Monitor
  • The zero-bezel industrial PCAP touch LCD monitor AMG-10IPPE01T2 by Amongo features as below:
    • Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
    • Durable mechanical design to meet tough environmental conditions and requirements;
    • Surface hardness MoHs 7, Scratch resistant;
    • Wide temperature, starting at low temperature;
    • High reliability test, stable quality;
    • Customization service available;
    Application: Kiosks,
    Contact Us

Specifications

Model Name

AMG-10IPPE01T2

Screen Size

10.1"

Active Display Area(mm)

216.96(H)x135.6(V)

Pixel Pitch(mm)

0.1695(H)x0.1695(V)

Display Mode

Normally Black

Display Resolution(pixel)

1280x800

Contrast Ratio

262K

Display Color

1300:1

Brightness

300nits

Backlight

LED

Viewing Angles(CR=10)

160(H);160(V)

Response Time(Typ.Tr+Tf)

25ms

Touch Screen

PCAP Touch(10 points)

Light Sensor

Optional

Tempered glass

Optinal

Signal Connector

HDMI

Power Input

DC 12V

Touch Controller

USB

Dimension(VxHxT)mm

261x174.2x25

Operating Temperature

-20~60℃(non-condensation)

Storage Temperature

-30~70℃(non-condensation)

Relative Humidity

5~90(%RH)
