15 Inch Android All-In-One PC

  • 15 Inch Android All-In-One PC
  • The Android based all in one PC AMG-15PPC04T2 is a 15 inch industrial panel computer made by Amongo and it has been widely installed in parcel lockers and battery exchanging stations with the following advantages:
    • Famous brand LCD panels adopted to ensure a perfect and clear image color and wide view angels with LED back light for energy-saving;
    • Popular Android operation system for end users’ final development;
    • Supporting Ethernet / Wi-Fi / Bluetooth / GPS and other functions;
    • Flat surface design with PCAP touch screen to support front IP65 waterproof, dust proof and vandal proof with tempered glass;
    • Passed all the stability and reliability tests to ensure long time operation;
    • Customization could be offered to meet projects related with AI and IoT ;
    Application: IoT, Kiosks,
    Contact Us

Specifications

System

Model Name

AMG-15PPC04T2

CPU

ARM Cortex-A53 T820 Eight Core 64-bit 2.0GHz CPU

RAM

2GB(4GB optional)

EMMC

8GB(16GB optional)

OS

Android 6.0

HDMI port

1 x HDMI

USB ports

4 x USB; 1 x USB OTG

LAN

4G/3G, Ethernet, WiFi, GPS support

SD Card

Support

LED ports

2 x LED

Speaker port

1 x Speaker

Tel port

1 x Telephone

LCD

Screen Size

15.6"

Active Area(mm)

344.16(H)x193.59(V)

Pixel Pitch(mm)

0.17925(H)x0.17925(V)

Display Resolution

1920x1080

Display Color

Normally Black

Brightness(cd/㎡)

300nits

Contrast Ratio

800:1

Viewing Angles

170(H);170(V)

Response Time(Tr+Tf)

30ms

Backlight

LED

Optional

Tempered Glass

Optional

Touch Screen

PCAP Touch(10 points)

Mechanical

Dimension(VxHxT)mm

420x270x51.36

Environmental

Operating Temperature

0~50℃(non-condensation)

Storage Temperature

-20~60℃(non-condensation)

Relative Humidity

5~90(%RH)
