24 Inch Bezel-Free PCAP Industrial Panel PC

  • 24 Inch Bezel-Free PCAP Industrial Panel PC
  • The 24 inch industrial panel pc AMG-24PPC01T4 offered by Amongo is welcomed by customers worldwide for different applications with features as below:
    • Flat-screen design with high-end branded TFT LCD panels with LED backlight, lower power consumption, better image effect and wider view angles;
    • Fan-less cooling system with reliable Intel processor, industrial-grade components adopted to ensure continuously running;
    • Bezel-less pcap touchscreen, rapid touch response, better user experience;
    • IP65 front protection, dustproof, built to enhance and manage all industrial processes;
    • Option of tempered glass for vandal proof function;
    • Robust casing and structure design to withstand the most harsh conditions, anti-vibration, anti-shock;
    • Different mounting options: VESA mount, embedded mount etc.
    • Supporting various operation system of Windows, Android, Linux etc.;
    • Meet with reliability test for demanding industrial applications;
    • Passed necessary certificates like CE, RoHS, and ISO 9001 and 14001 etc.;
    Contact Us

Specifications

Model Name

AMG-24PPC01T4

CPU

Intel Bay Trail J1900 CORES 4 2.0GHz

Memory

DDR3L 1333/1066 4GB(optional)

HDD

HDD 1TB ST1000LM014 2.5 SATA

PS/2 Port

PS/2 mouse and keyboard port

VGA port

1x VGA port

HDMI port

1x HDMI port

COM ports

2x COM ports

USB 2.0 ports

4x USB 2.0

Ethernet ports

2x10/100/1000BASE-T Gigabit Ethernet

Audio

Mic-in,Line-out

Display Size

24"

Display Resolution(pixel)

1920x1080

Brightness(cd/㎡)

250

Contrast Ratio

1000:1

Pixel Pitch(mm)

0.27675x0.27675

Viewing Angle(CR=10)

170(H);160(V)

Backlight

LED

Type

PCT Touch(10 points)

Input Voltage

+12V 5~8A

Output Rating

65W(Max)

Operating Temperature

0~50℃

Storage Temperature

-20~60℃

Relative Humidity

5(%RH)~90(%RH)
